60:11:16 (Denso/JZE Bottom) - EV6 (USCAR) plug - 550cc/min, 55lb/hr@43PSI Injectors
- Description
- Testimonials
- Flow Testing
- Fuel Compatibility
- Vehicle Compatibility
- Vehicle Compatibility 2
- Legal Disclaimer
Made in THE USA in collaboration with Bosch, The Snake Eater Pro-Series 550's use only the highest quality internal components, materials and are ran through an incredible amount of injections before arriving at your door.
The SEP Pro-Series line is our top of the line, no expense spared, closest flow and offset matched injector line. These injectors are intended for the customer who is scratch building a motor, intends to run high rpm for long duration or simply wants to trust their fuel system to the best name brand in fuel injection.
SEP Pro-Series Customer PTS Fab running SEP Pro-Series Injectors on Methanol
Injectors will be within 1% flow variance on a multi point dynamic test.
Full Injector Flow/Offset report included in package and Plug and Play ECU tuning data for all SEP Injectors included with purchase via email request. (Plug and Play ECU data/Injector characteristics provided by Calibrated Success Inc./Greg Banish)
All known hydrocarbon fuels and oxygenators
Crank Horsepower Rating @58psi fuel pressure, 93 octane, V8 engine with 1 injector per cylinder: 650hp
Connector: uscar (EV6)
Flow Rate @43psi: 550cc/min, 55lb/hr @58psi 640cc/min, 64lb/hr
High Impedance 12.5 ohms coil
*** It is IMPERATIVE when running high flow fuel injectors you run a 10 Micron inline aftermarket fuel filter system!!! Failing to do so will allow debris COMMONLY found in pump gasses into the injector body and begin to alter fuel flow rates and/or cause TOTAL FAILURE of fuel injectors voiding your warranty and damaging your engine***
Direct OEM Fitments FOR 48mm aka "EV14 Medium" (please reference your OEM plug style and choose the appropriate option or adapter)
BMW:
- E46 M3 01-06, E90 / E92 / E93 M3 07+
Can am ATV:
- Outlander ATV 08
Dodge / Chrysler:
- Neon SRT-4, Caliber SRT-4, Hellcat/Trackhawk/Demon
Ford:
- Focus RS MK II-IV: Mustang GT500 07-14; Ford Mustang 2011+; Coyote Motors 2011+
Honda/Acura:
- Civic 02-05 Si, Civic 06-11, S2000 06-09, RSX 02-09, TSX 04-10
Infiniti:
- G35
Lamborghini:
- Gallardo 04-13
Nissan:
- 350Z, Patrol, Sentra SE-R Spec V 00-06, Titan 04+
Porsche:
- 996/997.1 TT
Direct OEM Fitments with added lower oring pn: Acd 217-1624/Gm 89017587
Chevrolet:
- Chevrolet Trailblazer SS 06-09 , C6 Corvette 05-07 LS2, Pontiac GTO 05-06 LS2
Cadillac:
- Cadillac CTS-V 06-07 LS2
Chevy LS family:
- LS2
This part is legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles and Racing Use Only Vehicles.
The following vehicles are considered Uncontrolled (Non-Emissions Controlled) Vehicles:
- 1965 and older U.S. manufactured California Certified vehicles
- 1967 and older U.S. manufactured Federally Certified vehicles
- 1967 and older Foreign manufactured vehicle
The following vehicles are considered Racing Use Only Vehicles:
- Racing Use Only Vehicles are vehicles that are used exclusively for competition and that are not registered and that may never be used on the street
WARNING: It is against the law to install this part on an Emissions Controlled Vehicle
The following vehicles are considered Emissions Controlled Vehicles:
- 1966 and newer U.S. manufactured California Certified vehicles
- 1968 and newer U.S. manufactured Federally Certified vehicles
- 1968 and newer Foreign manufactured vehicle
